Description
- Single piece Contractor Hinge Jig designed for recessing hinges in wooden doors & frames with a plunge router
- Easy to use with minimal setting-up time
- Clean & accurate recesses achieved every time
- Used on both inside and outside doors
- Angled position slots to prevent creep
- Four apertures for fire door requirements
Trend Hinge Recessing Jig Single Piece HINGE/JIG
Trend HINGE/JIG is a specialized tool designed to make the process of recessing hinges into doors and frames more precise and efficient.
Features:
Single piece Contractor Hinge Jig is designed for recessing hinges in wooden doors & frames with a plunge router
Easy to use with minimal setting-up time, completing the job both accurately & quickly
Used on-site & in joinery shops to increase productivity with excellent results
Four apertures for fire door requirements
No need for marking out in the conventional way
Quick & simple to set-up as the hinge is used as the pattern
Clean & accurate recesses are achieved every time. Suitable for timber based doors & square butt hinges
Can be used on both inside and outside doors, rebated frames and on maximum 25mm thick fixed stops
Use with a light duty plunge router with 1/4 inch collet
Long reach router cutter required, 12mm diameter with 70mm overall length
Angled position slots to prevent creep
Unibase may be needed
Product Specification:
Part Number: HINGE/JIG
Barcode: 5027654503300
Hinge Sizes Possible:
Length min.: 2 5/8″ (67 mm)
Length max.: 5″ (127 mm)
Width min.: 3/8″ (9.5 mm)
Width max.: 1 3/8″ (35 mm)
Width max. in 35mm rebate: 20 mm
Width max. in 44mm rebate: 30 mm
Door Sizes Possible:
Height min.: 6′ 5″ (1955 mm)
Height max.: 2100 mm*
Thickness min.: 5/8″ (16 mm)
Please note for doors over 2040mm the bottom hinge will be higher than 9″ up.
Max. hinge leaf width 20mm (35mm doors)
**images for illustrative purposes only – please refer to description and specification for full details of product**
