Laserliner 082.150A Digital Coating Thickness Gauge – Non-Destructive Measurement Tool

Description

• Coating thickness meter
• Non-magnetic coatings
• Ferrous detection
• USB data transfer
• 400 value memory

Laserliner 082.150A Coating Test-Master Coating Thickness Measuring Device 32005

This point precise coating thickness measuring instrument is suitable for insulating and non-magnetic coatings on non-ferrous metals. The base material is identified automatically (ferrous/ferromagnetic, non-ferrous/non-ferromagnetic). The device features one-point or two-point calibration to increase the measuring accuracy. 400 measured values can be saved to the internal memory and transferred to a PC via the USB interface for further analysis. Supplied with USB cable, batteries and carrying case.

Features:

Precise coating thickness measurement.
Suitable for non-magnetic coatings.
For insulating layers on metals.
Automatic base material detection.
Identifies ferrous & non-ferrous metals.
One-point and two-point calibration.
Stores up to 400 measurements.
USB interface for PC data transfer.
Ideal for inspection and analysis.
Supplied with USB cable, batteries & case.

Comes With:

1 x Laserliner 082.150A Coating Test-Master Coating Thickness Measuring Device
1 x Calibration references
1 x Software
1 x USB cable
1 x Batteries
1 x Carrying case

Product Specification:

Part number: 082.150A
Barcode: 4021563680597
Stock no: 32005
Coating thickness: Yes
Ferrous and non-ferrous: Yes
Single and continuous measurement: Yes
Mean value: Yes
Standard deviation: Yes
Zero adjustment: Yes
User calibration Yes
Measured Variable: Coating thickness
Coating Thickness Measuring Range: 0 1250 µm
Sensor Type: Magnetic-inductive (Fe), eddy current (NFe)
Port: USB
Memory: 80 measurements / mode
Power Supply: 2 x 1.5V LR03 (AAA)
Dimensions (W x H x D): 23 mm x 110 mm x 50 mm
Weight: 116g

**images for illustrative purposes only – please refer to description and specification for full details of product**
